Car Battery Cable for Sale

  • Conductor: Copper
  • Insulation: PVC
  • Insulation Color: Red,Black
  • Temperature Range: -20°C to +90°C
  • Nominal Voltage: 450/750V
  • Test Voltage: 1000V
  • Standard:IEC

Specification

  • Conductor

    Plain Annealed Copper Class

  • Insulation

    PVC

  • Sheath

    PVC

  • Min Operating Temperature

    -40°C

  • Max Operating Temperature

    90°C

  • Core Colours

    Red,Black

  • Sheath Colours

    Red,Black

  • Current Carrying Capacity

    For current ratings refer to IEC

The Characteristics of Car Battery Cable

Application:
Car Battery Cable is typically rated 600 volts but can also be rated 100 volts. The cable is known for its flexibility and durability, and many automatic and manual welding applications require the cable to hold up to repeated movement over rough surfaces.
Standard:
Car Battery Cable for Sale
Feature:
• Durability
• Tear resistance
• Abrasion resistance
• Melt resistance
• Resistant to oil, water and chemicals
• Impact resistance
Customer Service:
Being one of the leading Car Battery Cable manufacturers, we always put quality in the first place. In order to guarantee the performance of Car Battery Cable, ZW produce the cable in strict accordance with international standards. Our Car Battery Cable is very popular in the world. We promise to provide the qualified products for our customers. If you to know more information about Car Battery Cable price, just leave your message

Parameter

Conductor Size Stranding(0.25mm)225 Conductor Diameter(in.) Insulation Thickness(in.) Total Diameter(in.) Max Amp
6 AWG 253 0.20 0.06 0.32 115
4 AWG 370 0.23 0.06 0.35 150
2 AWG 634 0.30 0.06 0.42 205
1/0 1004 0.47 0.08 0.53 285
2/0 1255 0.43 0.08 0.59 325
4/0 2047 0.56 0.08 0.72 440
