Electrical Cable Supplier

  • Conductor: Copper
  • Insulation: PVC
  • Insulation Color: Red-Yellow-Green-Blue
  • Temperature Range: -20°C to +70°C
  • Nominal Voltage: 0.6/1KV
  • Test Voltage:3.5KV
  • Standard: IEC

Electrical Cable Supplier Specification

  • Conductor

    Plain Annealed Copper Class 2

  • Insulation

    XLPE Type

  • Sheath

     PVC Type

  • Min Operating Temperature

    -20°C

  • Max Operating Temperature

    70°C

  • Core Colours

    4 Core -Red-Yellow-Green-Blue

  • Sheath Colours

    Black

  • Current Carrying Capacity

    For current ratings refer to IEC Strandard

Electrical Cable Supplier

Being one of the leading Electrical Cable Supplier. Our focus is to continue producing quality cables to international standards whilst ensuring efficient & timely delivery of cables. We strive to provide superior after sales services to all our customers. This will ensure zero importation of cables into our country.We can supply low voltage power cabble, medium voltage power cable, high voltage power cable, steel tape armoured cable, and steel wire armoured cable.
Standard:
The product implement the standards GB/T5023, equivalent to IEC60 227. And it can also be made complying with ASTM, DIN, BS standards etc.
Our Vision:
To be the leading manufacturer of cables in the world.
Advantage:
Since 1993.
Free Sample.
30 Years Warranty.
Accept Lower MOQ.
Most sizes are in Stock.

Electrical Cable Supplier

Normal cross-sectional area of conductor (mm2) Normal thickness of insulation (mm) Normal thickness of sheath (mm) Approx. Overall diameter (mm) Approx. weight kg/km
        VV VY VLV VLY
4*4 1 1.8 14 327 294 226 193
4*6 1 1.8 16 421 385 270 233
4*10 1 1.8 19 637 592 382 337
4*16 1 1.8 21 909 858 504 453
4*25 1.2 1.8 24 1334 1273 701 640
4*35 1.2 1.8 27 1749 1681 871 804
4*50 1.4 1.9 29 2255 2179 1067 991
4*70 1.4 2.1 33 3121 3025 1405 1309
4*95 1.6 2.2 37 4264 4148 1881 7965
4*120 1.6 2.4 41 5278 5141 2272 2135
4*150 1.8 2.5 45 6487 6329 2778 2620
4*185 2 2.7 50 8074 7885 3434 3244
4*240 2.2 2.9 56 10497 10268 4403 4174
4*300 2.4 3.1 62 13080 12809 5428 5157
